An important addition to data literacy: AI-powered forensic data audit

The pollution lock effect

Traditional AQI monitoring systems did not account for this at all – thereby showing inaccurate AQI readings. For instance, monitoring factors traditionally looked at relative humidity and atmospheric pressure as separate pieces of information.

However, “Pollution Lock” is the point at which the air is no longer dispersing the pollutant, and the AI sees that the air is trapping the pollutant instead due to the interaction between variables like relative humidity and atmospheric pressure. This risk contour map, thus, visualizes the non-linear ‘Red Zone’ where specific thresholds of atmospheric pressure and relative humidity converge to create a structural trapping effect for urban pollutants.

By extension, using a correlation matrix, the dynamic bonds between weather variables are quantified – identifying the precise strength of the relationship between humidity, pressure, temperature, aerosol hygroscopicity (which is a substance’s ability to attract, adsorb, or absorb water molecules directly from the surrounding atmosphere), and the resulting AQI deviations – resulting in a correctional framework that can give a holistic and accurate view of the AQI at a given time.

Forensic audit of Delhi’s air quality for actual AQI readings

Forensic audit of Delhi’s Air Quality in 2023-2024 for actual AQI readings

As a case study, to bridge this ‘truth gap’ in Delhi’s AQI readings, the Polynomial-Enhanced Random Forest Regression (PERFR) model was used on the air quality data in Delhi during the 2023-2024 period.

Contrary to the former approach that considered real environmental factors affecting air quality only as secondary noise, this model tried to understand the interaction between the different factors affecting the aerosol mix being monitored by the AQI sensors.

Various interaction terms, like the (Humidity * Pressure) interaction, being more accurately predictive than individual weather variables, the following feature-importance ranking table – illustrating how the interaction between secondary variables (such as temperature and humidity) mathematically outweighs individual metrics in determining predictive accuracy – was arrived at.

The model found Relative Humidity (RH) to be the reason for the error in approximately 60% of the AQI data for Delhi. The model then plots the hygroscopic growth curve for the aerosol mixture found in the Delhi region and describes how water molecules coat dust particles to increase the apparent size of the dust as the sensor’s laser measures it – thus directly distorting AQI readings.

Ultimately, it was found that the sensors always over-reported in the winter months in Delhi with the sensors found to be over-reporting on 4 out of 5 days of high humidity in the 2023-2024 audit – resulting in a “ghost spike”.

On the other hand, the AQI monitors were under-reporting in extreme arid conditions (RH < 25%), with these conditions rarely occurring in the peak winter smog season.

The impact of the ghost spike

The ultimate test of this model happened from November 3-5, 2023, when Delhi’s air quality hovered around the hazardous saturation level of 479-500, leading to drastic GRAP restrictions on Stage III/IV, causing severe economic disturbances. Forensic results showed humidity peaked on these mornings, with relative humidity measured at 85%-92%. Therefore, applying the AI correctional framework, the sensors were over-estimating the amounts by 30%.

Ghost data: Approximately 150 points of the hard spike were recognized as water molecules fooling the sensors (hygroscopic growth). Ultimately, it so happened that the decisions about taking emergency economic actions under GRAP-III/IV restrictions were based on atmospheric interference affecting the livelihoods of millions of Delhi-NCR residents.

Real-world deployment

Using AI and the PERFR model, an industrially applicable invention was made, which if deployed within the real-world air quality monitoring infrastructures, would directly influence socio-economic decisions affecting the daily lives of a city’s residents – an indispensable need for Smart Cities.

The system can be applied to government air quality monitoring networks, smart city infrastructures (where real-time, reliable pollution measurements are critical for public safety and urban planning), low-cost sensor networks to upgrade their effective accuracy, and in environmental compliance systems used by regulatory agencies for emissions monitoring and enforcement.

Why engineers need forensic data literacy

This is an achievement which most engineers can replicate, provided they are adequately trained in forensic data literacy and on integrating AI to develop real-world applications.

By integrating AI architectures for filtering environmental “noise” at the point of collection, the “Truth Gap” can be eliminated, and this was only one such example which can open doors to several inventions.

There is a growing need in developing economies like India for their aspiring engineers and researchers to be trained to transition from academic publication to achieving measurable social impact, because in these countries the tightrope walk between economic success and environmental hazards is much longer than developed nations.

Every invention which can reduce this distance is a direct contributor to India’s journey for development and no one is better placed to contribute to this than India’s current and future engineers.

(Kunal Goyal is an engineer and researcher specializing in advanced sensor technologies, energy systems, and industrial materials strategy.)
